Glass Fermenter

Fermentation Tanks, Stainless Conical Fermenters

The glass fermenter is a common fixture for biological fermentation in labs. The borosilicate glass vessel features high-temperature resistance and corrosion resistance. Due to the transparency of the glass, it is easy to monitor the state of the culture medium. There are four working volumes available for you to choose from: 5L, 10L, 15L and 20L. We can adjust the function of modules according to your needs.

Inquiry Form

Basic Configuration

PH
- On-line check and measure
- Peristaltic pumps for adding the acid and base solutions
- Control range: 2-12pH; measuring accuracy: ±0.01 pH; control accuracy: ±0.1 pH
- Automatic alarm
DO
- On-line check and measure
- Combined with rotation speed
- Range: 0-100% or 0-200%; accuracy: ±1%
- Automatic alarm
Defoaming
- Automatic control and alarm
- Stainless steel electrodes
- Peristaltic pumps for adding antifoaming agents
Feeding
- Manual control and automatic alarm
- Stainless steel electrodes
- Peristaltic pumps for feeding
Temperature
- PID control
- Measuring range: 0-150℃; control range: 15-45℃; control accuracy: ±0.2℃
- pt100Ω temperature probe
- Built-in electric heating device for controlling the temperature inside
Rotation Speed
- Automatic control and alarm
- Servo motor
Pressure
- Pressure gauge, manual control (standard)
- Pressure transducer, automatic control (optional)
Air Flow
- Rotameter, manual control (standard)
- Mass flow meter, automatic control (optional)
- PALL filter with the accuracy of 0.2μm
Sterilizing Mode

Off-site sterilization
Control Mode

Siemens PLC, 10.4“ color LCD touch screen
Computer
- Configure recording function (optional)
- Siemens remote control software configure recording function (optional)
- Printer (optional)
