SJN II Series Stainless Steel Extraction Tank
Stainless Steel Extraction Tank, Sanitary Extract Processing Tank
SJN II series stainless steel extraction tank are widely applied to starch, glucose, monosodium glutamate, and dairy product. These extraction tanks can effectively concentrate heat sensitive materials at low temperature in vacuum.
| Model | SJN II 500 | SJN II 1000 | SJN II 1500 | SJN II 2000 | SJN II 3000 | ||
| Max. Evaporation Capacity (kg/h) | 500 | 1000 | 1500 | 2000 | 3000 | ||
| Vapor Pressure (Mpa) | 0.03-0.09 | 0.03-0.09 | 0.03-0.09 | 0.03-0.09 | 0.03-0.09 | ||
| Vapor Consumption (kg/h) | 250 | 500 | 750 | 1000 | 1500 | ||
| Water Consumption (t/h) | 5 | 10 | 15 | 15 | 25 | ||
| Heating Surface of Added Heater (m2) | 8 | 10 | 16 | 22 | 28 | ||
| Condensation Surface of the Secondary Vapor from the Second Effect (m2) | 16 | 20 | 26 | 32 | 38 | ||
| Vapor Inlet (mm) | 40 | 50 | 50 | 65 | 80 | ||
| Cooling Water Inlet (mm) | 50 | 50 | 65 | 65 | 65 | ||
| Dimension | Length (L) | 4000 | 5000 | 5500 | 6500 | 6800 | |
| Width (W) | 1500 | 1700 | 1800 | 2000 | 2000 | ||
| Height (H) | 3300 | 3500 | 4000 | 4200 | 4500 | ||
| Evaporation Temperature (℃) | First Effect | 80-90 | 80-90 | 80-90 | 80-90 | 80-90 | |
| Second Effect | 55-70 | 55-70 | 55-70 | 55-70 | 55-70 | ||
| Design Pressure | 0.09 | 0.09 | 0.09 | 0.09 | 0.09 | ||
| Vacuum Degree | First Effect | -0.04 | -0.04 | -0.04 | -0.04 | -0.04 | |
| Second Effect | -0.06 | -0.06 | -0.06 | -0.06 | -0.06 | ||
| Concentration Ratio | 1.1-1.3 | 1.1-1.3 | 1.1-1.3 | 1.1-1.3 | 1.1-1.3 | ||
